LiPoly Tester, Meter, and Alarm

Specifications Use our LiPoly Tester, Meter, and Alarm: As a Lipo tester: to test your batteries before and after a match. Supports voltage tests for 1s-8s Lipo/ Li-ion/ LiMn/ Li-Fe batteries Use as a low voltage Lipo alarm: battery monitor checker will keep buzzing when the voltage is below 3.3v. You can change the alarm voltage value using the black button between 2 speakers. As a Lipo meter: to get detailed statistics on your battery: read the value of battery cell voltage, total voltage, lowest cell voltage, and remaining battery capacity. Specification Operating Parameter Voltage detection precision: within 0.01 V. Unit voltage display range: 0.5~4.5 V Total voltage display range: 0.5~36 V 1S test mode voltage range: 3.7~30 V Low voltage alarm mode: 2-8 S Alarm set value range: OFF~2.7~3.8 V Weight: Dimensions: 25mm x 40mm x 11mm. 1″ x 1.57″ x 0.43″ Use: Connect the balance connector to the pins of the tester and it will show the battery statistics on the large LED display Supports reverse connection protection.
